RG-S5760C-48GT4XS-HP-X Switch Overview
Ruijie RG-S5760C-48GT4XS-HP-X Enterprise Layer 3 Managed Switch It has 48 × 10/100/1000BASE-T PoE/PoE+ ports and 4 × 1GE/10GE SFP+ uplink ports. The switch is equipped with advanced capabilities, including Virtual Switch Unit (VSU) virtualization, field-proven Layer 3 routing protocols, and in-depth security policies, which makes it an ideal solution for aggregation layers in medium to large networks.
Highlights
-
High-Density PoE Port Configuration: Provides 48 × 10/100/1000BASE-T PoE/PoE+ ports and 4 × 1GE/10GE SFP+ uplink ports, supporting flexible deployment options.
-
VSU Virtualization: Supports Virtual Switch Unit (VSU) technology, allowing multiple physical switches to operate as a single logical unit, simplifying network management and enhancing reliability.
-
Advanced Layer 3 Routing: Offers comprehensive Layer 3 routing protocols, including static routing, RIP, OSPF, IS-IS, and BGP, supporting both IPv4 and IPv6 networks.
-
Robust Security Features: Incorporates multiple security mechanisms such as ACLs, DHCP Snooping, ARP inspection, and support for SSH and SNMPv3 for secure management.
-
High Reliability: Features hot-swappable power modules with redundancy, ensuring continuous operation and service reliability.
-
Efficient Management: Supports various management methods, including CLI, web-based management, Telnet, and integration with Ruijie’s INC for simplified operations and maintenance.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5760C-48GT4XS-HP-X:
| Product Model | Category | Description |
| RG-PA600I-P-F | Power Supply Module | 600W AC power supply module, supporting hot-swapping and redundancy. |
| RG-PA1000I-P-F | Power Supply Module | 1000W AC power supply module, supporting hot-swapping and redundancy. |
| M5000X-4XS2CQ | Expansion Module | 4 × 10GE SFP+ ports and 2 × 100GE QSFP28 ports, enhancing uplink capacity. |
| XG-SFP-SR-MM850 | Optical Transceiver | 10GE SR module, SFP+ form factor, LC connector, 850 nm, up to 300 m over OM3 MMF. |
| XG-SFP-LR-SM1310 | Optical Transceiver | 10GE LR module, SFP+ form factor, LC connector, 1310 nm, up to 10 km over SMF. |
Specifications
| Parameter | Specification |
| Model | RG-S5760C-48GT4XS-HP-X |
| Service Ports | 48 × 10/100/1000BASE-T PoE/PoE+ |
| Uplink Ports | 4 × 1GE/10GE SFP+ |
| Switching Capacity | 880 Gbps |
| Packet Forwarding Rate | 402 Mpps |
| MAC Address Table | 64,000 entries |
| ARP Table Size | 24,000 entries |
| IPv4 Unicast Routes | 24,000 entries |
| IPv6 Unicast Routes | 14,000 entries |
| IPv4 Multicast Routes | 4,000 entries |
| IPv6 Multicast Routes | 2,000 entries |
| Power Module Slots | 2 (supporting 1+1 redundancy) |
| Fan Module Slots | 2 pluggable modular fans |
| Management Ports | 1 × Management, 1 × Console, 1 × USB 2.0 |
| Expansion Slots | 1 × expansion module slot |
| Dimensions (W × D × H) | 442 mm × 420 mm × 43.6 mm (17.40 in. × 16.54 in. × 1.72 in., 1 RU) |
| Weight | Approximately 5.7 kg (including all modules) |
| Power Supply | AC 100–240V, HVDC 192–288V |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| MTBF | ≥ 200,000 hours |
