網路交換機 S6110-48MG4VS2QXS-UP 48xMulti-Gig & 40G/上行鏈路 PoE++ 園區交換機
Safe, Fast, 100% Genuine. Your Reliable IT Partner.
Best Price Assurance, Bulk Savings, Trusted Worldwide.
Proven Expertise, Trusted Solutions
- 8 Years, 100+ Countries
- 10000+ Customers/Projects
- CCIE, HCIE, H3CIE, RCNP, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts
Join Partner Network
- Exclusive Discounts/Service
- Credit Terms/Priority Supply In Hongkong
48×1/2.5/5 Gbps 多千兆 + 4×25 Gbps SFP28 + 2×40 Gbps QSFP28 PoE++ 園區/核心交換機
概述
NS-S6110-48MG4VS2QXS-UP 配備 48 個多千兆 (100 Mb-5 GbE) PoE/PoE+ 連接埠、4 個 25 Gbps SFP28 上行鏈路、2 個 40 Gbps QSFP28 上行鏈路，以及高達 1600 預算，升級： V++ 上行鏈路，以及高達 1600 預算區升級。該設備可透過 VSU 堆疊，支援高級 L3 路由和安全性策略。
強調
-
混合速度接入： 48 個 100 Mb/1/2.5/5 GbE RJ45 PoE/PoE+ 連接埠（連接埠 1–24 支援 HPoE，功率高達 90 W）
-
高速上行鏈路：4×25 Gbps SFP28 + 2×40 Gbps QSFP28
-
440 Gbps 容量 / 625 Mpps 轉發
-
強大的 PoE：高達 1 600 W PoE 預算（配備 2×RG-PA600I-PF）
-
模組化可靠性：2個PSU插槽，3個風扇插槽，支援熱插拔
推薦配件
| 產品名稱 | 類別 | 描述 |
|---|---|---|
| NS-PA600I-PF | 交流電源模組 | 600W電源模組（400W PoE+200W機殼） |
| NS-PA1000I-PF | 交流電源模組 | 1000W電源模組（800W PoE + 200W機殼） |
| NS-RMK-1U | 機架安裝套件 | 19吋1U安裝支架 |
與類似型號比較
| 模型 | 連接埠和上行鏈路 | 交換容量 | 轉送率 | PoE/PoF功能 | 冗餘功能 |
|---|---|---|---|---|---|
| Ruijie RG-S6000C-48GT4XS-E | 48×1 GbE RJ45、4×10 GbE SFP+ | 256 Gbps | 192兆位元/秒 | 沒有任何 | 雙 PSU 插槽、雙啟動快閃記憶體、1 個風扇插槽 |
| NS-S6000C-48GT4XS-E | 相同的 | 相同的 | 相同的 | 沒有任何 | 相同的 |
| 銳捷RG-S6150-24VS8CQ-X | 24×1/10/25GbE SFP28，8×40/100GbE QSFP28 | 2.8 Tbps | 沒有任何 | 雙 PSU、4 個風扇模組、雙啟動快閃記憶體 | |
| NS-S6150-24VS8CQ-X | 相同的 | 相同的 | 相同的 | 沒有任何 | 相同的 |
| Ruijie RG-S6150-48VS8CQ-X | 48×1/10/25GbE SFP28，8×40/100GbE QSFP28 | 4 Tbps | 沒有任何 | 雙 PSU、4 個風扇模組、雙啟動快閃記憶體 | |
| NS-S6150-48VS8CQ-X | 相同的 | 相同的 | 相同的 | 沒有任何 | 相同的 |
| 銳捷RG-S6110-48MG4VS2QXS-UP | 48×100 Mb–5 GbE PoE/PoE+、4×25 GbE SFP28、2×40 GbE QSFP28 | 840 Gbps | 625兆位元/秒 | 高達 1600 W PoE++ | 雙 PSU 插槽、3 個風扇插槽 |
| NS-S6110-48MG4VS2QXS-UP | 相同的 | 相同的 | 相同的 | 相同的 | 相同的 |
| 銳捷RG-S6120-24XMG4XS4VS-UP-H | 24×100 Mb–10 GbE PoE/PoE+/PoE++、4×10 GbE SFP+、4×25 GbE SFP28 | 760 Gbps | 565兆位 | 高達 1650 W PoE++ | 雙 PSU 插槽、3 個風扇插槽 |
| NS-S6120-24XMG4XS4VS-UP-H | 相同的 | 相同的 | 相同的 | 相同的 | 相同的 |
| 銳捷RG-S6120-20XS4VS2QXS | 20×1/2.5/10 GbE SFP+、4×10/25 GbE SFP28、2×40 GbE QSFP+ | 912 Gbps | 678兆位 | 沒有任何 | 雙 PSU 插槽、2 個風扇插槽 |
| NS-S6120-20XS4VS2QXS | 相同的 | 相同的 | 相同的 | 沒有任何 | 相同的 |
規格摘要
| 範圍 | 細節 |
|---|---|
| 模型 | NS-S6110-48MG4VS2QXS-UP |
| 訪問連接埠 | 48×100 Mb/1/2.5/5 GbE PoE/PoE+（1–24 上的 HPoE，最大 90 W/連接埠） |
| 上行鏈路端口 | 4×25 Gbps SFP28，2×40 Gbps QSFP28 |
| 交換容量 | 840 Gbps |
| 轉送率 | 625兆位元/秒 |
| MAC/ARP/IPv4 路由 | 32千/16千/16千 |
| CPU / 記憶體 / 存儲 | 1.2 GHz 單核心 / 2 GB DDR4 / 1 GB 快閃記憶體 |
| PoE 預算 | 最大 1600 W（2 個 PSU） |
| 尺寸（寬×深×高） | 442×420×43.6毫米；6.11公斤 |
| 環境 | 0℃～45℃；10～90% 相對濕度 |
