Cisco Catalyst C1200-8FP-2G Full PoE Managed Switch
保證安全結賬
安全、快速、100% 正品。您值得信賴的 IT 合作夥伴。
最佳價格保證、大量節省、全球信賴。
標籤點
Overview
The Cisco Catalyst C1200-8FP-E-2G is part of Cisco’s Catalyst 1200 Series, delivering reliable, Layer 3-capable Gigabit Ethernet connectivity with advanced PoE+ power for modern SMB environments. Designed for unified data and power delivery, it provides high PoE budget (120 W), seamless manageability, and silent operation—making it ideal for powering access points, IP cameras, and VoIP devices across office, retail, and branch deployments.
The C1200-8FP-E-2G combines 8 × 1 GbE PoE+ ports and 2 × 1 GbE RJ-45/SFP combo uplinks in a compact fanless chassis, delivering 20 Gbps switching capacity and 14.88 Mpps forwarding rate. With IEEE 802.3af/at PoE+ support and 120 W total budget, it provides both data and power in a single cable—simplifying infrastructure while supporting Layer 2/3, VLAN, ACL, QoS, and Static Routing features.
Offering enterprise-grade performance in a small form factor, the C1200-8FP-E-2G is a smart-managed switch with an extended PoE power budget and fanless design. Its 120 W PoE+ capability supports high-density wireless and surveillance applications. Managed via Cisco Business Dashboard, Mobile App, or Web UI, it ensures intuitive deployment, monitoring, and troubleshooting in secure SMB networks.
Highlights
-
8 × 1 GbE PoE+ ports (120 W total budget) + 2 × 1 GbE RJ-45/SFP combo uplinks
-
20 Gbps switching capacity / 14.88 Mpps forwarding rate
-
IEEE 802.3af/at PoE+ (up to 30 W per port)
-
Layer 3 static routing, VLAN, ACL, QoS, IPv4/IPv6
-
Fanless design for silent operation
-
Managed via Cisco Business Dashboard, Mobile App, or Web UI
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| RCKMNT-1RU-1K= | Rack-Mount Kit | 19″ 1U brackets compatible with all Catalyst 1200 Series models |
| CAB-CONSOLE-RJ45 | Console Cable | RJ-45 console cable for initial configuration and management |
Compare with Similar Models
| Model | Ports & Uplinks | PoE Budget | Fan | Power Supply | Positioning Notes |
|---|---|---|---|---|---|
| C1200-8P-E-2G | 8 × 1 GbE PoE+ + 2 × 1 GbE combo | 67 W | Fanless | External | Compact PoE+ model for light loads |
| C1200-8FP-E-2G (this model) | 8 × 1 GbE PoE+ + 2 × 1 GbE combo | 120 W | Fanless | External | Higher PoE power budget for multi-device deployments |
| C1200-16P-2G | 16 × 1 GbE PoE+ + 2 × 1 GbE SFP | 120 W | Fanless | Internal | 16-port PoE+ expansion |
| C1200-24P-4G | 24 × 1 GbE PoE+ + 4 × 1 GbE SFP | 195 W | Fanless | Internal | Mid-size PoE+ option for larger networks |
| C1200-24T-4X | 24 × 1 GbE + 4 × 10 GbE SFP+ | — | Fanless | Internal | Data-only model with 10G uplinks for aggregation |
Specification Summary
| Parameter | Specification Details |
|---|---|
| Model Name | Cisco Catalyst C1200-8FP-E-2G |
| Product Type | Managed Layer 3 Gigabit Ethernet PoE+ Switch |
| Downlink Ports | 8 × 10/100/1000 Mbps RJ-45 PoE+ (IEEE 802.3af/at compliant) |
| Uplink Ports | 2 × 1 GbE RJ-45/SFP combo ports (copper or SFP active per port) |
| Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.88 Mpps |
| Packet Buffer | 1.5 MB (shared) |
| MAC Address Table | 8,000 entries |
| PoE Standard | IEEE 802.3af/at (PoE+) |
| Total PoE Budget | 120 W |
| Per-Port Power Max | 30 W |
| Jumbo Frames | Up to 9,000 bytes |
| QoS Queues | 8 hardware queues per port (WRR + Strict Priority) |
| VLAN Support | Up to 255 active VLANs, 802.1Q tagging, Voice VLAN |
| Spanning Tree | 802.1D STP, 802.1w RSTP, 802.1s MSTP, PVST+ |
| Link Aggregation | IEEE 802.3ad LACP (up to 4 groups) |
| Multicast Control | IGMP Snooping v1/v2/v3 |
| Layer 3 Routing | IPv4 and IPv6 static routing |
| DHCP Relay | Supported |
| Access Control | ACL (L2–L4) Filtering |
| Authentication | IEEE 802.1X (RADIUS) |
| Security Features | Port Security, DHCP Snooping, BPDU Guard, DoS Prevention |
| Traffic Management | 802.1p CoS/DSCP trust and remark, Ingress/Egress rate limiting |
| Management Interface | Web UI, Cisco Business Dashboard, Mobile App |
| Management Protocols | SNMP v1/v2c/v3, HTTP/HTTPS, TFTP, DHCP |
| Logging & Monitoring | Syslog, Event Logs |
| Cooling Design | Fanless (silent operation) |
| Power Supply | External Adapter (100–240 VAC, 50/60 Hz) |
| Power Consumption | ≈ 13 W (no PoE load), up to 140 W (max PoE load) |
| Operating Temperature | 0 °C to 50 °C (32 °F to 122 °F) |
| Storage Temperature | −25 °C to 70 °C (−13 °F to 158 °F) |
| Operating Humidity | 10 – 90% RH (non-condensing) |
| MTBF | ≈ 2,050,000 hours |
| Form Factor | Desktop / 1U Rack-mount (optional kit) |
| Dimensions (W × D × H) | 185 × 269 × 43 mm (7.3 × 10.6 × 1.7 in) |
| Weight | 1.49 kg (3.28 lb) |
| Certifications | UL 62368, CSA 22.2, CE, FCC Class A |
| Warranty | Cisco Limited Lifetime Hardware Warranty |
