Cisco C9200-24P-E Access Enterprise Switch

The Cisco Catalyst 9200-24P-E is a 1 RU fixed-port PoE+ access switch purpose-built for U.S. campus and branch deployments—from powering IP cameras in Los Angeles distribution centers to driving Wi-Fi 6 access points in New York City offices.

Running Cisco IOS XE with the Network Essentials license on an x86 CPU paired with the Cisco UADP 2.0 ASIC, it delivers 24 auto-sensing 10/100/1000 RJ-45 PoE+ downlinks, a hot-swappable network-module slot, and field-replaceable power and fan units for “always-on” resiliency.

Centralized management is available via Cisco Catalyst Center or Meraki Dashboard.

Overview

Highlights

  • 24 × 1 GbE PoE+ Downlinks & Modular Uplinks
    24 autosensing 10/100/1000 RJ-45 PoE+ ports plus one hot-swappable module slot (supports C9200-NM-4G, C9200-NM-8X, C9200-NM-2Q)

  • Robust PoE Power Budget
    Primary PWR-C6-600WAC PSU supplies 370 W PoE+; add a second PWR-C6-600WAC for 740 W total

  • High-Performance Fabric
    128 Gbps non-blocking switching capacity; 95.23 Mpps forwarding rate (stacked: 288 Gbps, 214 Mpps)

  • StackWise-160 Resiliency
    Stack up to 8 switches with 160 Gbps bidirectional stacking bandwidth, NSF/SSO, and cross-stack EtherChannel for < 50 ms failover

  • Advanced Layer 2/3 Features
    IEEE 802.1Q VLANs; STP/RSTP/MSTP; LACP; static and dynamic IPv4/IPv6 routing (OSPF/EIGRP/RIP); ACLs; PBR; multicast; QoS classification and scheduling

  • Enterprise-Grade Security
    AES-128 MACsec encryption; Secure Boot with Trust Anchor Module; 802.1X; DHCP Snooping; Dynamic ARP Inspection; IP Source Guard; scalable ACLs

  • Programmability & Telemetry
    Open APIs (NETCONF/RESTCONF, gNMI, NX-API/Python SDK); on-box scripting; streaming telemetry; Cisco DNA Center / Meraki Dashboard integration

  • Energy-Efficient & Always-On Design
    IEEE 802.3az Energy-Efficient Ethernet; low-power fan management; FRU-redundant fans and power supply units

Recommended Accessories

Accessory Category Description
C9200-NM-4G Network Module 4 × 1 GbE SFP uplinks for fiber aggregation
C9200-NM-8X Network Module 8 × 10 GbE SFP+ uplinks for high-speed aggregation
C9200-NM-2Q Network Module 2 × 40 GbE QSFP+ uplinks for ultra-high-speed uplinks
PWR-C6-600WAC Power Supply 600 W AC FRU-redundant power supply (370 W PoE+)
FAN-T2= Fan Module Field-replaceable fan tray for N+1 cooling redundancy
Rack-Mount Kit Mounting Hardware Standard 19″ rack-mount accessory kit (usually included)



Comparison with Similar Models

Feature C9200-24P-E C9200-24T-E C9200-24P-A
Ports & Uplinks 24 × 1 GbE PoE+ + modular 24 × 1 GbE data + modular 24 × 1 GbE PoE+ + modular
License Network Essentials Network Essentials Network Advantage
Available PoE Power 370 W (single); 740 W (dual) N/A 370 W (single); 740 W (dual)
Switching Capacity 128 Gbps 128 Gbps 128 Gbps
Forwarding Rate 95.23 Mpps 95.23 Mpps 95.23 Mpps
Stacking Bandwidth 160 Gbps 160 Gbps 160 Gbps
Ideal Use Case PoE+ endpoint aggregation Data-only edge access Advanced PoE+ with SD-Access



Specifications

Parameter Specification
Product Code C9200-24P-E
Description Catalyst 9200 24-port PoE+ Switch with Network Essentials software
Software Cisco IOS XE with Network Essentials license
Downlink Ports 24 × 10/100/1000 RJ-45 auto-sensing PoE+
Uplink Expansion 1 × hot-swappable module slot (4G/8X/2Q)
Default Power Supply 1 × PWR-C6-600WAC (600 W AC)
Available PoE Power 370 W (primary PSU); 740 W (with secondary PSU)
Stacking Bandwidth 160 Gbps
Switching Capacity 128 Gbps full-duplex
Stacked Capacity 288 Gbps full-duplex
Forwarding Rate 95.23 Mpps (64-byte packets); 214 Mpps stacked
Virtual Networks (VRFs) 4
MAC Address Table Up to 32,000 entries
IPv4 Routes Up to 10,000 direct IPv4 routes
IPv6 Routes Up to 2,000 entries
Jumbo Frame Support Up to 9,198 bytes
Dimensions (HxWxD) 1.73″ × 17.5″ × 13.8″ (4.4 × 44.5 × 35.0 cm); with FEP & fans: 1.73″ × 17.5″ × 15.4″
Weight 12.12 lb (5.5 kg)
MTBF 422,310 hours
Operating Temp. / Humidity 32 °F–113 °F (0 °C–45 °C); 5–90% non-condensing
Certifications & Compliance FCC Class A; UL/CSA 60950-1; CE; RoHS


More Details

Quality Certifications

product_iso14001   product_iso9001   product_rohs   product_reach    product_ce      product_fcc

Do you have any question about the Cisco C9200-24P-E Switch?

Please Chat with us now!

or leave us an message on sales@network-switch.com.

Warranty

100% Low Price Guarantee

Network-switch.com provides high-quality products at low wholesale prices

100% Quality Assurance

All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by CCIE Engineers.

Free Technical Support

Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee

You can contact our customer service team to exchange or return any product that you bought from us.

Flexible Secure Payment & Shipment

Verified authorization: Mcafee Secure, VeriSign Secured

Return Material Authorization (RMA) Process

Standard Warranty Policy

Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year

The Support Contacts

If your Cisco products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.

Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
C
Carol Kim
Great overall service

Very pleased with both the product and service. Its rare to find such a reliable supplier.

Learn More

Frequently Questions and Answers

Q1. What is the difference between PoE, PoE+, and UPoE?

A: PoE delivers up to 15.4W per port, PoE+ supports up to 30W, while UPoE (Cisco-specific) provides up to 60W using all four cable pairs.

Q2. Can Catalyst 9200 Series switches stack with Catalyst 2960-X/XR switches?

A: No, Catalyst 9200 and 2960-X/XR switches have different CPU architectures and stacking protocols, making them incompatible for stacking.

Q3. What airflow does the Cisco Catalyst 9200 Series support?

A: The airflow direction for Catalyst 9200 Series switches is from front and sides toward the back.

Q4. Can both console ports be used simultaneously on Cisco Catalyst 9200 switches?

A: No, the RJ-45 console mirrors the USB console output when USB is active, making simultaneous use impossible.

Q5. Can Cisco Catalyst 9200 Series switches act as wired switches?

A: Yes, they provide connectivity for both wired devices and wireless access points, offering consistent network experience with SD-Access.

Q6. Do Catalyst 9200 switches support auto-baud on console ports?

A: No, auto-baud detection is not supported on these switches.

Q7. What uplink modules are supported on Cisco Catalyst 9200 Series switches?

A: Supported uplink modules include either 4x 1-Gigabit Ethernet or 4x 10-Gigabit Ethernet ports.

Q8. Which older Catalyst series does Catalyst 9200 replace?

A: Catalyst 9200 primarily replaces the Catalyst 2960-X/XR Series, but existing 2960-X/XR units remain usable.

Q9. What key features does the Cisco Catalyst 9200 Series offer?

A: It offers robust security, StackWise stacking, modular uplink options, redundant power supplies and fans, as well as PoE+ support.

Q10. Does the C9200L include an uplink module?

A: Yes, each C9200L model includes a fixed uplink module with 4x10-Gigabit Ethernet (SFP+) ports.

Q11. How many Ethernet ports does the C9200L-48P-4X-E have?

A: The C9200L-48P-4X-E has 48 Gigabit Ethernet PoE+ ports.

Q12. What uplink interfaces are available on C9200L-48P-4X-E?

A: The C9200L-48P-4X-E supports four 10-Gigabit Ethernet SFP+ uplink ports.

Q13. Is the C9200L-48P-4X-E stackable?

A: Yes, it supports stacking using Cisco StackWise-80 technology for unified management.

Q14. What is the default power supply of the C9200L-48P-4X-E?

A: The default power supply is an AC power unit.

Q15. What’s the difference between Catalyst C9200 and C9200L?

A: The Catalyst 9200 has modular fans and interchangeable uplink modules, whereas the 9200L has fixed uplinks and non-modular fans.

Q16. Can C9200 and C9200L switches stack together?

A: No, modular (C9200) and fixed (C9200L) models cannot be stacked together due to differences in their architectures.
