ST UPC to ST UPC Duplex Single Mode Fiber Patch Cable, 2.0mm OFNR
$6.60
Connectivity Solutions
Overview
Description
Reviews
Q&A
Return and Refund
DOWNLOAD
Solutions
Features
Enable Seamless Connectivity for Your Network
Network-Switch.com offers the ability to configure the pre-set compatibility of either connector of the AOC cable online with NS BOX to connect Cisco to Arista, Dell to Juniper, and any other mixes of configurations.
Overview
The NS ST UPC to ST UPC Duplex Single Mode Fiber Patch Cable is a rugged OS2 interconnect solution designed for long-distance links in entrance facilities, telecommunications rooms, data centers, and industrial or legacy ST-based environments. Featuring ST UPC duplex connectors on both ends with bayonet-style coupling, this cable provides secure, quick-connect terminations ideal for applications where frequent mating and robust mechanical engagement are required.
Constructed with bend-insensitive G.657.A1 fiber and a 2.0mm riser-rated (OFNR) tight-buffered jacket, this duplex patch cable delivers low insertion loss, high return loss, and consistent performance even when routed through tight spaces. It supports 1G/10G/25G/40G/100G/400G Ethernet connections and is well-suited for long-distance transmission—up to 10 km at 1310 nm or up to 40 km at 1550 nm—making it an excellent choice for single mode backbones, cross-connects, and point-to-point links.
Need help matching ST patch cords to your existing panels, test gear, or long-haul runs? Contact us now and our team will assist in validating your configuration before deployment.
Key Specifications
| Specification | Details |
|---|---|
| Vendor Name | Network-Switch (NS) |
| Product Type | ST UPC to ST UPC Duplex Single Mode Fiber Patch Cable |
| Connector A | ST UPC Duplex |
| Connector B | ST UPC Duplex |
| Fiber Count | 2 Fibers (Duplex) |
| Fiber Grade | G.657.A1 (Compatible with G.652.D) |
| Fiber Mode | OS2 9/125 μm |
| Wavelength | 1310 nm / 1550 nm |
| Polarity | A (Tx) to B (Rx) |
| Cable Type | Tight-buffered |
| Cable Outside Diameter (OD) | 2.0 mm |
| Flame Rating | Riser (OFNR) |
| Min. Bend Radius (Optical Fiber) | 10 mm |
| Min. Bend Radius (Fiber Cable) | 10/5D (Dynamic/Static) |
| Connector Durability | 1000 mating cycles |
| Tensile Strength | 90/150 N (Long/Short Term) |
| Insertion Loss | ≤ 0.30 dB |
| Return Loss | ≥ 50 dB |
| Attenuation @ 1310 nm | 0.4 dB/km |
| Attenuation @ 1550 nm | 0.3 dB/km |
| Operating Temperature | -10 to 70 °C (14 to 158 °F) |
| Storage Temperature | -20 to 70 °C (-4 to 158 °F) |
| Recommended Distance @ 1310 nm | Up to 10 km (application dependent) |
| Recommended Distance @ 1550 nm | Up to 40 km (application dependent) |
| Applications | 1G/10G/25G/40G/100G/400G Ethernet, industrial/legacy ST systems, DC/telecom backbones |
Why Choose NS ST UPC to ST UPC Duplex OS2 Patch Cables?
-
Secure bayonet-lock ST connectors – Fast, twist-lock coupling provides reliable connections in lab, industrial, and legacy telecom environments.
-
Long-distance OS2 performance – Supports extended reach links up to 10 km @ 1310 nm and 40 km @ 1550 nm.
-
Bend-insensitive G.657.A1 fiber – Reduced attenuation when bent or twisted, simplifying routing and ongoing maintenance.
-
Low loss & high return loss – Tight optical performance supports high-speed Ethernet services up to 400G.
-
Riser-rated 2.0mm construction – Durable tight-buffered OFNR jacket for use in riser spaces, racks, trays, and conduits.
Length Options
Standard stocked lengths:
Available in a range of common duplex lengths ideal for frame-to-frame, rack-to-rack, and equipment-to-panel connections in telecom rooms, data centers, and industrial sites.
Custom lengths:
Custom lengths, jacket colors, labeling, and polarity options are available on request to align with specific cabling standards, plant layouts, and routing paths.
